tecnology

Back to solid solutions

Safe, low pressure and ambient temperature hydrogen storage. A concrete solution to energy transition.

MetHydor supply tailored metal hydride hydrogen storage systems for stationary, marine and transport sectors.

100% recyclable

Complete recyclability

Safe low pressure

<40 bar means direct electrolyser coupling

Thermal Management

Air or Liquid

Long life

Up to 30 years

Ambient Temperature

-10°C to +40°C in operation

Metal Hydrides

Solid Hydrogen Storage

The Solid Hydrogen Storage system is a hydrogen storage solution that uses the metal hydride technology to store large amount of hydrogen in reduced volumes and safely.

The system is able to operate at low pressure and ambient temperature, and it can be directly coupled with electrolysers and fuel cells.

Research and development

Patented Solutions

Patented solutions have been prototyped, studied and developed into a system that is able to exploit the characteristics of metal hydrides for solid state hydrogen storage.

Research and development

Patented Solutions

Patented solutions have been prototyped, studied and developed into a system that is able to exploit the characteristics of metal hydrides for solid state hydrogen storage.

Flexible solutions

Modular Design

The modular tank design enables to adapt the system to the available space and geometries maximizing the performances.

Flexible solutions

Modular Design

The modular tank design enables to adapt the system to the available space and geometries maximizing the performances.

Made of stainless steel

Resilience

The use of stainless steels and the robustness of the tanks make it possible to install the storage system in harsh environment like nautical applications.

Made of stainless steel

Resilience

The use of stainless steels and the robustness of the tanks make it possible to install the storage system in harsh environment like nautical applications.

Embedded control

Intelligence

The embedded control system enables to thermically couple the hydrogen storage system with fuel cells and electrolysers, increasing the total system efficiency and enabling the integration.

Embedded control

Intelligence

The embedded control system enables to thermically couple the hydrogen storage system with fuel cells and electrolysers, increasing the total system efficiency and enabling the integration.

solutions

Hydor System ®

The design of the storage system can be adapted to the available spaces.

Each system is designed according to the specific needs of the customer in terms of size, technical specifications, form.

The system can be exploited for large stationary hydrogen storage systems or custom design.

Storage Capacity
H2 capacity (nominal)
kg
0,6
Energy stored
kWh
20
Charge
Pressure
bar
20 – 35
Temperature
°C
15 – 25
H2 Flow max
kg/h
0,4
Discharge
Pressure
bar
1.5 – 30
Temperature
°C
40
H2 Flow max
kg/h
0,4
Dimensions
(L x B x H) – mm
1500 x 295 x 75
Weight
kg
75
External temperature
°C
-20 to 50
Certifications
Ped (2014/68/UE)
Play Video

about us

References

Established in 2021 as a joint venture between companies active in the hydrogen field since many years.

MetHydor, “beyond water”, aims to exploit the metal hydride technology to safely store large quantities of hydrogen at low pressure and ambient temperature, but not only…

45 kWh - 1.4 kgH2

South Italy

Hydor System made of 1x Hydor S 45
installed in a Italian SME for backup power purpose

240 kWh - 7.2 kgH2

BIIM

Hydor System made of 2x Hydor Rack S 120 Installed onboard the BIIM boat, coupled with a 45kW fuel cell system

480 kWh - 14.4 kgH2

BZero

Hydor System made of 6x Hydor Rack S 240 Installed in the BZero power plant, coupled with a 200kW fuel cell system

240 kWh - 7.2 kgH2

Australia

Hydor System made of 1x Hydor S 240 installed in Australia for the storage of green hydrogen produced from renewables

5 kWh - 0.15 kgH2

Environment Park

Hydor System made of 1x Hydor Custom S 5 Installed onboard a cargo bike, coupled with a 300W fuel cell system

60 kWh - 1.8 kgH2

Cartif

Hydor System made of 2x Hydor S 30 Installed on a research test rig, coupled with a 2kW fuel cell system and 2.5kW electrolyser

about us

Methydor

Established in 2021 as a joint venture between companies active in the hydrogen field since many years.

MetHydor, “beyond water”, aims to exploit the metal hydride technology to safely store large quantities of hydrogen at low pressure and ambient temperature, but not only…

Mission

Our Mission is to unleash the Renewable Energy potential, introducing a green hydrogen storage system

Vision

We dream of a cycle economy based on renewable energy and recyclable systems

Partnership

We aim to cooperate with research and industrial partners to complement hydrogen systems

collaborations

Scientific supervision

Methydor exploit the knowledge and expertise of the Univesity of Torino.

Through a continuous open innovation collaboration with the Department of Chemistry and NIS, Methydor aims to keep a high level of R&D.
